Dead Weight Pressure Gauge Tester | N.S., 100 PSI w/NIST Traceable Certificate
Description
The Dead Weight Pressure Gauge Tester [PN: T-03-830] is precision built to primary pressure standards, used for testing, setting, calibrating or repairing pressure measuring devices within the test points 15 psi (100 kPa) to 10,000 psi (70,000 kPa).
Pressure calibration points produced by the deadweight tester are accurate to within ± 0.1% of the reading certified traceable to the N.I.S.T. The tester provides consistent, repeatable accuracy, maintaining its pressure for an appreciable length of time regardless of temperature changes, slight leaks in the pressure system, or changes in volume of the pressurized system due to movement of a Bourdon tube or other device.
Features
- PN: T-03-830
- Calibration Range: 15 psi to 10,000 psi
- Accuracy: ± 0.1% (NIST traceable)
- Materials:
- Pump Body: Aluminum alloy
- Piston/Cylinder: Stainless Steel
- Reservoir Volume: 1.5 pints (0.7 liters)
- Operating Fluids: SAE 20 oil or phosphate/glycol hydraulic fluids
- O-Ring Seals: Standard Buna-N; optional Ethylene Propylene
- Accessories: Carrying case, connection pipes, wrenches, spare O-ring kit
- Dimensions: Carrying case (10 x 10 x 22 inches)
- Certification: Includes NIST traceability document.
Downloads
Specifications
| Specs | 1305D |
|---|---|
| Accuracy | Accuracy within 0.1% of produced pressure (adjusted for standard gravity conditions; compensation for local gravity effects may be required) |
| Operating Pressure | 15 psi to 10,000 psi maximum |
| Reservoir Volume | Approximately 1.5 pints (0.7 liter) |
| Pump Body Material | Aluminum alloy |
| Piston and Cylinder Material | Piston: 440C Stainless Steel Cylinder: 416 Stainless Steel |
| Operating Fluid | 1305D – SAE 20 automotive or machine oil 1305DH – Phosphate or glycol base hydraulic fluids, (Monsanto Skydrol 500B-4 or equal) NOTE: Not for use with water medium. For oxygen service applications, refer to models 1327DO or 1327CMO. |
| Weight Material | Non-magnetic die cast zinc alloy, ASTM AC41A |
| O-Ring Seals | Standard (1305D) – Buna-N Optional (1305DH) – Ethylene Propylene |
| Accessories | Metal carrying and storage boxes Lower connection offset pipe assembly Black connection pipe 1/4 & 1/2 NPT Female adapters Wrenches (1″x1-1/8″), (1/4″x1″), (5/8″) Pointer puller set Installation and Operation Manual Spare O-ring kit |
| Certification | Standard: NIST traceability document provided with each unit |
| Carrying Case Dimensions | 10 x 10 x 22 (inches) |
| Weight Box Dimensions | 9 x 9 x 8.5 (inches) |
